Medical Grade Monitor 21

Medical Grade Monitor 21

• LCD size (inch) - 21.5" (16:9)
• Resolution -1920 (W) x 1080 (H) Pixels
• Brightness - (cd/m2) 250 (typical)
• Contrast ratio -  5000:1 (typical)
• Viewing angle - 178°/178° (typical)
• System Gamma Correction: Factory calibrated gamma 2.0 & DICOM
• Color Temperature: Factory calibrated 4500K, 5500K, 6500K, 7500K
• Power Requirement Medical grade
• Power adaptor: input: 100~240V AC 50~60Hz; output: 12V DC/5. 42A
• Function Keys OSD rotary knob x 1 Input source quick selection x 1 Monitor sleep x 1
• Dimensions (L x W x H) 530.3 x 325 x 53 mm
• Weight 6.2 kg
• Operating Temperature 0°C~40°C
• Storage Temperature - 20°C ~60°C
• Medical Certifications CE, FCC Class B part, AAMI ES 60601-1, EN 60601-1VGA (DB-15) Input: 1DVI-D Input: 1
• Component Input: BNC x 1 (Y/Pb/Pr, R/Gs/B, R/G/B/C-Sync, R/G/B/H-Sync/V-Sync)
• Output (loop through): BNC x 1 (Y/Pb/Pr, R/Gs/B, R/G/B/C-Sync, R/G/B/H-Sync/V-Sync)
• CVBS Input: BNC x 1 (NTSC, PAL)Output (loop through): BNC x 1 (NTSC, PAL)
• S-Video Input: 1
• Output (loop through): 1
• Audio Input: Phone jack x 1
• Output 2W x 2
• HDMI 1.4 (optional) Input: 1
• Output (loop through): 1
• 3G-SDI (Optional) Input: 1
• Output (loop through): 1
• Touch Screen Touch screen (optional) N/A
